HUUM CHIMNEY SET THROUGH WALL BACKSIDE CONNECTION

HUUM CHIMNEY SET – Through the wall backside connection

The HUUM Chimney set is a ready-made solution for a safe and aesthetic installation of a chimney for HUUM wood-burning stoves through a wall. The set includes all the necessary components for assembly, ensuring reliable insulation, proper draft, and the durability of the entire system. It is the ideal choice for saunas requiring a side connection to the chimney.

Product Features

• Purpose: Installation of a chimney for HUUM wood-burning stoves with a through-the-wall exit.
• Compatibility: Suitable for all HUUM wood-burning stoves.
• Safety: The set includes a T600 insulation plate and specifies minimum safety distances:
  • 500 mm for single-wall components;
  • 50 mm for double-wall components.

Set Contents

• Single-wall chimney adapter (adjustable length 150–250 mm).
• Welded base for a double-wall chimney.
• Double-wall chimney, 0.25 m.
• 90-degree double-wall elbow.
• Cover plate (two parts).
• T600 insulation plate for wall and ceiling.
• Double-wall chimney, 1.0 m.
• Adjustable wall bracket (50–150 mm).
• Chimney cap.

Advantages

• Complete kit: all necessary elements for installation in one box.
• Safety: a well-thought-out system with insulation materials and safety distances.
• Reliability: a welded base and high-quality components ensure durability.
• Ease of installation: adjustable elements (adapter, bracket) simplify the process.
• Aesthetic look: the cover plate conceals the wall pass-through, creating a neat interior.

Application

Used for installing a chimney for HUUM wood-burning stoves in private and commercial saunas where flue gases need to be exhausted through a side wall.

Result

With the HUUM Chimney set, you get a safe, professional, and aesthetic installation of the chimney system, which ensures the proper operation of the stove and complete fire safety.

Ideal for

• Owners of HUUM wood-burning stoves;
• Sauna builders and installers;
• Projects where the chimney needs to be routed through a wall instead of the roof.
